Motorised Corner Folding Garage Doors
- Sectional sliding gates are unique in that if there isn’t enough space for telescopic or bi-fold gates, we can move it around the corner and up the side, similar to a sideways folding sliding gate. This example features a track on the bottom and a guide on top.
- Even at low ambient heights, the folding boom allows for a maximum boom length of 4.5 m. Even when the barrier is opened, the pushrod keeps the front half of the barrier boom horizontal. The articulated boom system is intended for heavy use in the parking area. These folding arm boom barriers may also be operated by mobile phone applications, which record entry and exit logs for each user, making the data available to authorities in the event that an occurrence has to be investigated.
- Attractive glazing
- Clear cut shape & fashionable designs available to suit clients choice
- Garage doors can be locked in open or closed position
- Control to stop anytime while garage door is moving
- Increased personal security with driveway garage door operated from the safety of your car
- Quick release disengaging mechanism inside garage enables changeover to manual operation in case of power failure
- Infrared sensor system reverses the direction of the door if any obstruction cuts across the invisible light beam
- Facility for Emergency side Entrance Door
- Easy to operate through push button/ Remote control
- Heavy duty bottom guiding track & top mounted hung track for slide folding operation of the garage door
- A total safety system, automatic slide folding garage doors are designed to meet all operational & safety needs
- Smooth and Noiseless Function
- These garage doors are widely used and Economical option among all the types of garage doors
- Our slide folding garage doors are available in single side or double side slide folding suggested to suit actual site condition
PRODUCT |
Motorised Corner Folding Garage Doors |
||
| DOOR TYPE | Single side / Bi-parting Type | ||
DOOR DIMENSION |
|||
| Width Min./Max. | Single Leaf : 1600/16000mm Double Leaf :3200/32000mm |
||
| Height Min./Max. | 1600/11000mm Larger Dimension on request |
||
| Opening Direction | Horizontal Corner Folding | ||
| Mounting Location | Inside | ||
| Mounting Surface | Bottom Rail: RCC/Steel Columns : RCC/Steel |
||
| Garage Door Mounting | On Top Track Mechanism | ||
GATE STRUCTURE |
|||
| Outer Frame | Tubular box section (or Customized design available on request) |
||
| Internal Design | Customized design ( vertical and horizontal design ) | ||
| Bottom Rail | “U” guide bottom track ( Mild Steel, Galvanised steel, Stainless Steel ) | ||
| Bottom Rollers | Steel with Nylon bottom guide rollers ( Mild Steel, Galvanised steel, Stainless Steel ) | ||
| Mechanism | Specially designed turning bearing rollers with turning door panels | ||
| Top Guide Rollers | Sealed ball bearing rollers both side mounted on top running track for support & smooth movement of door. | ||
PATTERNS/DESIGNS |
|||
| Other available gate material | Stainless Steel, Mild Steel, Hot dip Galvanized Steel, Aluminium Steel |
||
| Sheets | M.S/GI/Perforated /Aluminium sheets Polycarbonate / Acrylic / PVC Sheet/Glass/Wood/WPC Wood/Fundermax panels |
||
| Ornamental Designs | On Request or as per client or architect design | ||
| Options Available | Spikes as per requirement Wicket door/Side doors in the similar pattern as the main garage door Any type of Customized Design can be made on request |
||
FINISH |
|||
| Surface Finish | Standard: Primer Finish Optional: Enamel Painting/Duco/PU painting/ Powder coating/ Hot deep Galvanising |
||
DETAILS FOR AUTOMATION SYSTEM |
|||
| Drive Unit | Imported & Indian make electromechanical drive having features such as powerful startup & thermal sensors Single( A.C & D.C )/Three Phase |
||
| Emergency Operation | Manual release knob | ||
| Accessories (Optional) |
|
||
- Hospitals
- Pharmaceuticals
- Aircraft
- Shipyards
- Food Industries
- Retail Malls
- Automobiles
- Logistics
- Chemical Industries
- Residential and Educational Places
