Galvanized Rolling Shutters
- Our GI steel rolling shutters are certain to be a long-term investment for your company. Your product, made of the toughest materials, will survive the environment, resisting corrosion and retaining its exterior for years to come. Bengaluru Enterprises manufactures roll-formed roller shutters with galvanised steel slats for improved durability. The steel slats’ heavy-duty nature allows them to withstand the sometimes harsh circumstances of industrial/commercial locations while requiring minimum maintenance.
- If damage does occur, the damaged slat can be replaced separately. This ensures that movement is smooth and unobtrusive throughout the product’s lifespan. For your convenience, this rolling shutter may be activated electrically.
- Our GI steel roller shutters are ideal for meeting the specific requirements of huge complexes and facilities, adding security and functionality to all openings and entrances. The GI is one of our most versatile roller shutters, and it can be found in a broad range of commercial and industrial applications, including retail units, shop fronts, shopping malls, department stores, supermarkets, and loading bay doors in industrial sites. It may be used to shield windows and doors.
- Our shutters are manufactured from the best quality metals which ensure long lasting performance
- The bottom profile of the door is incorporated with additional stiffeners to provide an additional strength
- Steel, aluminums or stainless steel grill rolling shutters are available in various designs
- Our shutters are manufactured from the best quality metals which ensure long lasting performance
- Our drives have weight carrying capacity until 2500Kgs
- Motorised rolling shutters are self sufficient and can be operated by a single push button
- Our shutters are in-build with high performance drives and intelligent controls
- In case of power failure, these doors can be operated manually using a hand crank or chain drive
- Our Drives are inbuilt with Special Anti Drop device and additional Electromagnetic brake to ensure that the door does not free-fall in any worst conditions
- Finger-tip control to open and close shutters of any size with the utmost ease from a single push-button switch or a radio remote control transmitter
- Noiseless operation and Excellent strength
- Easy installation and Low maintenance
- Our shutters are manufactured from the best quality metals which ensure long lasting performance
- Grill rolling shutters are one of the options that you may choose as your shutter curtain among the many types of roller shutters
- Grill rolling shutters are light but strong and allow air ventilation while ideal for creating a friendly barrier from the outside
PRODUCT |
Galvanized Motorized Rolling Shutters |
||
GATE DIMENSION |
|||
| Width Min./Max. | 1000/12500mm | ||
| Height Min./Max. | 1000/14000mm Max. Area 120.0 Sqm |
||
| Opening Direction | Vertical | ||
| Mounting Location | Center | ||
| Opening/Closing Speed | 0.05-0.1mtr /sec | ||
| Wind Resistance Up to | 90Km/Hr * Higher wind pressure on request |
||
GATE STRUCTURE |
|||
| Slat Material | CRC G.I Steel Slats available in 0.9 mm, 1.0 mm & 1.2 mm thickness | ||
| Slat Profile | Corrugated Profile (RSC 78, RSC 88, RSC 113) Optional Flat Profile |
||
| Side Guide | GI Steel Side guides 75 mm, 100 mm, 150 mm & 200 mm wide Box guides with wind hooks for higher wind pressure as optional |
||
| Bottom Profile | GI Steel Bottom Plate with Angle Stiffener Rubber bottom seal as optional |
||
| Roller Shaft | Heavy duty GI Steel strong suspension Tubular shaft without springs | ||
| Side Brackets | M.S plate 3 mm to 10 mm,as per the opening dimension | ||
| Hood Cover | Galvanized Steel sheet | ||
FINISH |
|||
| Surface Finish | Primer finish as standard | ||
| Painting (Optional) | Enamel/ Powder coating /Duco/ Epoxy/ PU | ||
DETAILS FOR AUTOMATION SYSTEM |
|||
| Control Type | Casing made of compact impact-resistant material incorporating operating buttons for shutter operation. Specific IP rating provided as per the requirement. Deadman/Pulse Control suggested application wise. |
||
| Drive Type | Imported make Indirect /Direct Connecting Drive selection made depending on the space opening availability, no of operations subjected etc. Drive with integral breaking system with Long life expectancy |
||
| Drive Unit | Electric Motor(Imported Make) Single Phase/Three Phase | ||
| Emergency Operation | Manual operation by Hand chain or hand crank | ||
| Options Available | Perforation In Slat profile Rolling Grill Wicket Door for pedestrian entry Vision windows at human height level |
||
| Accessories(Optional) can be integrated with advanced control |
|
||
- Hospitals
- Pharmaceuticals
- Aircraft
- Shipyards
- Food Industries
- Retail Malls
- Automobiles
- Logistics
- Chemical Industries
- Residential and Educational Places
